Our precision angular contact ball bearings are available in H-type and Type-B separable designs, covering both metric and inch series. With a standard contact angle of 15°±2° and precision grades P5, P4, and P2, they are ideal for high-speed and combined-load applications.
Precision Angular Contact Ball Bearings are developed for demanding applications that require high rotational accuracy, excellent running stability, and reliable performance under combined radial and axial loads. The uploaded document shows that this product category includes H-type angular contact ball bearings and Type-B separable angular contact ball bearings, available in both metric and inch series. The standard contact angle is 15°±2°, and the available precision grades are P5, P4, and P2.
The H-type series is suitable for precision assemblies where high-speed capability, controlled internal geometry, and stable running performance are essential. The Type-B separable design offers greater flexibility during installation and maintenance, making it especially useful in systems where assembly convenience and replaceability are important. These structures make angular contact bearings a strong choice for machine tools, spindles, precision transmissions, instrumentation, and automation systems.
Compared with standard radial bearings, angular contact ball bearings are better suited to applications involving axial positioning and combined loading. Their optimized contact angle design helps improve rigidity, motion control, and operating consistency, especially in equipment where precision and speed must be maintained at the same time. The metric and inch product coverage also supports a broader range of global replacement and OEM applications.
If you are looking for a precision bearing solution for high-speed rotation, accurate load transfer, and flexible configuration options, our H-type and Type-B separable angular contact ball bearings offer a dependable and professional choice.
H-type metric bearing Standard contact angles:15°±2°
Precision grades:P5、P4、P2
specicaien | Dimension(mm) | Basic Load Rating(N) | Weight | ||||||||
Radial | Static Axial | ||||||||||
Dynamic | Static | ||||||||||
d | D | B | d1 | D1 | r | Ciocr1s | Ciona2cla | Co | Cax | g | |
635H | 5 | 19 | 6 | 11.1 | 15.05 | 0.3 | 1960 | 1570 | 752 | 1390 | 8.79 |
626H | 6 | 19 | 6 | 10.6 | 14.55 | 0.3 | 1890 | 1510 | 764 | 1510 | 8.37 |
607H | 7 | 19 | 6 | 11.1 | 15.05 | 0.3 | 1960 | 1570 | 752 | 1390 | 7.9 |
638/8H | 8 | 16 | 6 | 10.1 | 13.9 | 0.2 | 1430 | 1150 | 671 | 217 | 4 |
608H | 8 | 22 | 7 | 12.45 | 17.65 | 0.3 | 2900 | 2320 | 1130 | 2080 | 12.3 |
609H | 9 | 24 | 7 | 13.95 | 19.15 | 0.3 | 3150 | 2520 | 1310 | 2440 | 15 |
61900H | 10 | 22 | 6 | 14 | 18 | 0.3 | 2260 | 1810 | 1010 | 1910 | 9.77 |
6000H | 10 | 26 | 8 | 14.85 | 21.15 | 0.3 | 4030 | 3220 | 1620 | 2990 | 18.8 |
6200H | 10 | 30 | 9 | 16.8 | 23.6 | 0.6 | 5280 | 4220 | 2170 | 3980 | 30.5 |
61901H | 12 | 24 | 6 | 15.9 | 20.6 | 0.3 | 2510 | 2010 | 1250 | 1410 | 10.7 |
6001H | 42 | 28 | 8 | 16.85 | 23.15 | 0.3 | 4380 | 3500 | 1900 | 3530 | 21 |
6201H | 12 | 32 | 10 | 18.3 | 26.4 | 0.6 | 7500 | 6000 | 3780 | 2750 | 35.1 |
61902H | 15 | 28 | 7 | 18.95 | 24.07 | 0.3 | 3580 | 2860 | 1780 | 3380 | 15.5 |
6002H | 15 | 32 | 9 | 20.6 | 26.8 | 0.3 | 4700 | 3760 | 2260 | 4260 | 29.5 |
6202H | 15 | 35 | 11 | 21.51 | 29 | 0.6 | 7310 | 5850 | 3290 | 6090二 | 44 |
61903H | 17 | 30 | 7 | 21 | 26 | 0.3 | 3550 | 2840 | 1830 | 3490 | 16.8 |
6203H | 17 | 40 | 12 | 24.23 | 32.7 | 0.6 | 8210 | 6570 | 3830 | 7110 | 64.1 |
61904H | 20 | 37 | 9 | 25.55 | 31.35 | 0.3 | 5460 | 4370 | 3080 | 5880 | 36.4 |
6004H | 20 | 42 | 12 | 27.2 | 34.8 | 0.6 | 8370 | 6690 | 4360 | 8220 | 67.6 |
61905H | 25 | 42 | 9 | 30.3 | 36.7 | 0.3 | 6090 | 4870 | 3890 | 7490 | 42.7 |
6205H | 25 | 52 | 15 | 33.52 | 43.64 | 0.6 | 14600 | 11700 | 9120 | 8890 | 126 |
61906H | 30 | 47 | 9 | 35.3 | 42 | 0.3 | 6170 | 4930 | 4240 | 5500 | 48 |
61907H | 35 | 55 | 10 | 41.1 | 48.9 | 0.6 | 9370 | 7490 | 7310 | 5500 | 74.7 |
6007H | 35 | 62 | 14 | 43.75 | 53.25 | 0.6 | 14900 | 11900 | 9840 | 18800 | 154 |
61908H | 40 | 62 | 12 | 46.7 | 55.3 | 0.6 | 12300 | 9850 | 9570 | 10500 | 111 |
6008H | 40 | 68 | 15 | 49.25 | 59.1 | 1 | 16400 | 13100 | 12200 | 22300 | 187 |
6009H | 45 | 75 | 16 | 54.2 | 65.8 | 1 | 21500 | 17200 | 15100 | 29000 | 236 |
H-type metric bearing
Inner diameterd from 50mmto 140mm
Standard contact angles:15°±2° Precision grades:P5、P4、P2
Sspcihcation | Dimension (mm) | Basic Load Rating(N) | Weight | ||||||||
Radial | Static Axial | ||||||||||
Dynamic | Static | ||||||||||
d | D | B | d1 | D1 | r | Ciocin) | Cisruacenia | Co | Cax | 9 | |
61910H | 50 | 72 | 12 | 57.1 | 64.9 | 0.6 | 12400 | 9940 | 10700 20900 | 135 | |
6010H | 50 | 80 | 16 | 59.2 | 70.8 | 1 | 22100 | 17700 | 16300 21400 | 252 | |
6210H | 50 | 90 | 20 | 62.3 | 77.7 | 0.6 | 33600 | 26900 | 22900 43600 | 465 | |
61911H | 55 | 80 | 13 | 62.7 | 72.3 | 0.6 | 18000 | 14400 | 15200 29400 | 180 | |
6012H | 60 | 95 | 18 | 70.8 | 84.2 | 1.1 | 29100 | 23300 | 22400 43000 | 399 | |
6212H | 60 | 110 | 22 | 75.4 | 94.6 | 0.6 | 一 | 40300 | 37600 72600 | 797 | |
61913H | 65 | 90 | 13 | 73 | 82.1 | 1 | 18500 | 14800 | 16900 32800 | 207 | |
6017H | 85 | 130 | 22 | 99.4 | 115.6 | 1.1 | 二 | 38400 | 44000 93000 | 897 | |
61920H | 100 | 140 | 20 | 112 | 128 | 1 | 一 | 34700 | 45600 90100 | 796 | |
61928H | 140 | 190 | 24 | 155 | 175 | 1 | 二 | 66100 | 101000109000 | 1670 | |
Type B (separable) metric bearings
Inner diameterd from 3mm to 50mm
Standard contact angles:15°±2° Precision grades:P5、P4.P2
Specicatian | Dimension(mm) | Basic Load Rating(N) | Weight | ||||||||
Radial | Static Axial | ||||||||||
Dynamic | Static | ||||||||||
d | D | B | d1 | D1 | r | Ciecr | Ciosrocnuso | Co | Cax | 9 | |
623B | 3 | 10 | 4 | 5.2 | 7.45 | 0.15 | 398 | 318 | 110 | 181 | 1.53 |
604B | 4 | 12 | 4 | 6.6 | 9.4 | 0.2 | 595 | 476 | 173 | 284 | 2.15 |
624B | 4 | 13 | 5 | 6.75 | 10.2 | 0.2 | 728 | 582 | 202 | 330 | 3.04 |
634B | 4 | 16 | 5 | 7.65 | 12.35 | 0.3 | 1170 | 942 | 337 | 545 | 5.01 |
625B | 5 | 16 | 5 | 7.65 | 12.35 | 0.3 | 1170 | 942 | 337 | 545 | 4.7 |
626B | 6 | 19 | 6 | 10.15 | 14.85 | 0.3 | 1380 | 1100 | 439 | 721 | 8.12 |
607B | 7 | 19 | 6 | 10.65 | 15.35 | 0.3 | 1390 | 1110 | 446 | 735 | 7.59 |
608B | 8 | 22 | 7 | 12.15 | 17.85 | 0.3 | 2050 | 1640 | 674 | 1100 | 11.5 |
6000B | 10 | 26 | 8 | 14.2 | 20.85 | 0.3 | 2830 | 2260 | 959 | 1560 | 18.8 |
6001B | 12 | 28 | 8 | 16.7 | 23.35 | 0.3 | 3420 | 2730 | 1300 | 2140 | 20 |
6002B | 15 | 32 | 9 | 20.6 | 26.8 | 0.3 | 4700 | 3760 | 2260 | 4260 | 29.2 |
6003B | 17 | 35 | 10 | 22.8 | 29.2 | 0.3 | 3950 | 3160 | 1730 | 2890 | 38.2 |
6006B | 30 | 55 | 13 | 38.2 | 47.1 | 0.6 | 12700 | 10200 | 8850 | 15300 | 115 |
6007B | 35 | 62 | 14 | 43.75 | 53.25 | 0.6 | 16700 | 13400 | 12400 | 22100 | 156 |
6210B | 50 | 90 | 20 | 62 | 78.6 | 0.6 | 37500 | 30000 | 27400 | 33400 | 439 |
H-type inch Bearing
Inner diameterd from 0.25 inch (3.175mm )to 0.5inch (12.7mm)
Standard contact angles:15°±2° Precision grades:P5、P4、P2
spectcatan | Dimension (in./mm) | BasicLoad Rating(N) | Weight | ||||||||
Radial | Static Axial | ||||||||||
Dynamic | Static | ||||||||||
d | D | B | d1 | D1 | r | Coec | Cosrocia | Co | Cax | 9 | |
R4H | 0.25 | 0.625 | 0.196 | 0.374 | 0.5 | 0.012 | 991 | 792 | 338 | 560 | 4.4 |
6.35 | 15.875 | 4.978 | 9.5 | 12.7 | 0.3 | ||||||
R8H | 0.5 | 1.125 | 0.3125 | 0.7283 | 0.8976 | 0.016 | 2410 | 1930 | 1170 | 1960 | 19.4 |
12.7 | 28.575 | 7.937 | 18.5 | 22.8 | 0.4 | ||||||
Inner diameterd from 0.125inch (3.175mm) to 0.25 inch (6.35mm)
Type-B (separable) inch bearing
Standard contact angles:15°±2° Precision grades:P5、P4、P2
Spectkction | Dimension (in./mm) | Basic Load Rating(N) | Weight | ||||||||
Radial | Static Axal | ||||||||||
Dynamic | Static | ||||||||||
d | D | B | d1 | D1 | ' r | Cen | CGaroen | Co | Cax | 9 | |
X1/8B | 0.125 | 0.3125 | 0.1094 | 0.1732 | 0.2618 | 0.005 | 349 | 279 | 89 | 145 | 0.54 |
3.175 | 7.9375 | 2.779 | 4.4 | 6.65 | 0.125 | ||||||
R2B | 0.125 | 0.375 | 0.1562 | 0.2047 | 0.2933 | 0.012 | 398 | 318 | 110 | 181 | 1.31 |
3.175 | 9.525 | 3.967 | 5.2 | 7.45 | 0.3 | ||||||
Y3/16B | 0.1875 | 0.5 | 0.1562 | 0.2756 | 0.4114 | 0.012 | 812 | 650 | 239 | 391 | 2.14 |
4.7625 | 12.7 | 3.967 | 7 | 10.45 | 0.3 | ||||||
Y1/4B | 0.25 | 0.625 | 0.196 | 0.3681 | 0.5039 | 0.012 | 916 | 733 | 300 | 49B | 4.4 |
6.35 | 15.875 | 4.978 | 9.35 | 12.8 | 0.3 | ||||||
